Product launch: Shear stacks, multi-axis

Noliac now provides a wide range of multi-axis piezoelectric shear actuator stacks, which can be used in a line of standard powerful solutions dedicated to applications such as nanopositioning, precision mechanics, active vibration cancellation, switches, semiconductor manufacturing and testing.
Product launch: Shear stacks, multi-axis

Standard features

  • X and X/Y motions
  • Smart design
  • -320 V to +320 V maximum operating voltage for all motions
  • Ideal for all stick and slip and nanopositioning applications
  • Top and bottom isolations included
  • Non-magnetic ultra-thin electrodes

Customized products
We can translate your applications' specific set of features into the best and optimal multi-axis actuator solution, which offers the performances you demand - based on optimized components and at the lowest possible cost.

Options available on demand:

  • Cryogenic capable
  • UHV capable
  • Custom shaped isolation endplates
  • Internal Diameter (central hole)
  • Custom colours and types of wires
  • Custom electrodes (materials, thicknesses)
  • Custom piezoelectric material

A piezo partner - what do we mean by that

Request for quote

We give you a competitive advantage by using our extensive knowledge to customize and optimize your piezo products. Thus, we will be your long-term piezo partner. Send your request today.
