Reliability



Piezoelectric actuators have demonstrated continuous operation in harsh conditions for above 108 cycles. However, because of the many different applications, there is no readily available model for reliability.



This figure would depend among others on:

  • Temperature, cooling
  • Humidity, contaminants
  • Mechanical loading, preload, vibrations
  • Operating spectrum
  • Electrical field

When designing a piezoelectric application, the following precautions should be taken in order to maximise the reliability:

  • Make sure that the actuator does not heat-up above the recommended temperature. Depending on the conditions, soft ceramics can heat-up significantly when operated continuously at high frequency.
  • Avoid exposing an actuator to high humidity levels. Humidity and contaminants can lead to electro-migration and eventually provoke a breakdown in the electrical insulation.
  • Make sure that the ceramic always operates in compression. PZT has a very limited tolerance to tensile stress. It is generally recommended to maintain a preload around 20% of the blocking force in all conditions. In particular, high acceleration must be taken into account.

Please note:

Every time the PZT drive voltage changes, the piezo element changes its dimensions (if not blocked). Due to the inertia of the PZT mass (plus additional mass), a rapid change will generate a force (pushing or pulling) acting on the piezoelectric actuator itself.



Tensile forces must be compensated for by a mechanical pre-load (inside the actuator or external) in order to prevent damage to the ceramics. Pre-load should be around 20% of the blocking force, with a springs stiffness around 1/10 or less compared to the PZT stiffness.

In sinusoidal operation with frequency f and amplitude ∆L/2, peak forces can be expressed as:

Fdyn=4 x ∏2 x meff x (∆L/2) x f2

Where:
Fdyn = peak dynamic force (N)
meff = effective mass (kg) = (1/3)mpiezo + mattached to the piezo
∆L = peak to peak displacement (meter)
f = frequency (Hz)

  • Make sure that the driving signal is smooth. Voltage spikes can generate large accelerations.
  • Load the actuator evenly. Uneven loading can rapidly lead to cracks in the ceramic material
  • Handle the parts carefully before mounting. Even if no damage is visible, small cracks can be initiated by shocks and further expand during cyclic loading.
  • Reduce the electrical field in order to improve reliability.
  • Avoid continuous operation under negative voltage, especially at high temperature.

Typical failure modes and their cause
