Parallelism

Parallelism ensures optimal performance of your piezo actuator stacks. Noliac offers parallelism with high accuracy for stacks with cross sections of 5x5 mm, 7x7 mm and 10x10 mm and a variety of lengths. 10x10 mm stacks have a plane parallelism of <10µm, and 7x7 mm stacks have a plane parallelism of <5µm.

Contact us and let us find the right solution
Contact us and let us find the right solution

If you have any questions about parallelism or other requirements, we are ready to take the method in use for other sizes as well. Please contact us using our Request for Quote form or contact sales.
